37° Flare flange connection O-ring seal
Type:BO3000...ORF
Flare Flange connection O-ring seal
F37 Flare flange according to SAE J518/ISO6162 37 Degree flare flange system is used for pipes of sizes ranging from ½" to 5". This is considered to be a fool proof solution for comparatively thin walled pipes. They can withstand pressures of up to 6000 psi. The standard connection styles offered conform to SAE Cd 61,SAE Cd 62.
Type：37°flare type
Standard：SAE J518, ISO6162, ISO6164
Size：1/2"-5"
OD of tube: 16mm-140mm (thickness≤7mm)
Pressure :3000Psi, 6000Psi, 42Mpa
Material：Carbon steel,316L
Seal: NBR,FKM
Certificate：CCS,ABS,DNV,RINA
Country/Region of Origin Code: China
Brand:JIERUI
Markets:
• Automotive
• Clean energy
• Marine engineering
• Industrial
• Rail Transit
• Oil and Gas
• Transportation
• Special vessel
• Agricultural machinery
With our expertise,JIERUI continue to create value for our customers by providing them with highly reliable products and services.
If you have any inquiries or need details about37° Flare flange,sales@dljierui.com. Thanks for your interest in our products.
